Triple Level Parking Lift – Stack Up to 3 Vehicles
Make better use of your building’s available height with this space-efficient triple-level parking lift. Its two overlapping platforms share just four posts, creating a clean, compact system capable of storing up to three vehicles.
- Store three vehicles within a single parking footprint
- Space-saving four-post design with two lifting platforms
- Ultra-low-profile entry ramps suitable for low vehicles
- 2,500kg middle-platform and 2,500kg upper-platform capacity
- 240V single-phase operation
- Ideal for private collections and commercial vehicle storage
The standard model has a maximum lifting height of 1,800mm. A reduced-height 1,550mm version is also available by special order for buildings with restricted headroom.
The displayed price is for the lift equipment only. Complete the quotation form below for personalised delivery pricing and information about multiple-unit orders.
£7,850.00 inc. VAT
Triple Level Parking Lift – Stack Up to 3 Vehicles
£7,850.00 inc. VAT
ex. VAT £7,850.00Make better use of your building’s available height with this space-efficient triple-level parking lift. Its two overlapping platforms share just four posts, creating a clean, compact system capable of storing up to three vehicles.
- Store three vehicles within a single parking footprint
- Space-saving four-post design with two lifting platforms
- Ultra-low-profile entry ramps suitable for low vehicles
- 2,500kg middle-platform and 2,500kg upper-platform capacity
- 240V single-phase operation
- Ideal for private collections and commercial vehicle storage
The standard model has a maximum lifting height of 1,800mm. A reduced-height 1,550mm version is also available by special order for buildings with restricted headroom.
The displayed price is for the lift equipment only. Complete the quotation form below for personalised delivery pricing and information about multiple-unit orders.
Product Details
Maximise Your Vehicle Storage Capacity
The Lift Giant triple-level parking lift allows up to three vehicles to be stored within a single parking footprint—one on each platform and a third at ground level.
Using two platforms supported by just four posts, the system makes excellent use of otherwise wasted building height. It is idea
...The middle platform can support vehicles weighing up to 2,500kg, while the upper platform has a maximum capacity of 2,500kg also.
Ultra-Low-Profile Platform Design
The two lifting platforms overlap when lowered, creating a particularly low drive-on height. This makes accessing the lift easier for low-clearance vehicles such as sports cars, supercars and racing cars.
Unlike triple-level systems that use two separate full-depth lifting platforms, the overlapping design reduces the overall platform thickness at ground level without compromising the lift’s storage capacity.
How the Triple-Level Lift Operates
The upper vehicle is loaded first. The middle platform raises both platforms together until the upper platform reaches its fixed top position and engages with the mechanical locking system.
The middle platform is then lowered so that the second vehicle can be loaded. Once this platform has been raised and secured, the third vehicle can be parked in the clear floor space below.
Vehicles must be removed in the reverse order, as this is a dependent parking system.
Concrete and Electrical Requirements
The lift must be installed onto a suitable reinforced concrete slab with a minimum thickness of 300mm. The condition, strength and suitability of the concrete should be confirmed before installation and is the clients responsibility.
Power is supplied by a 3kW, 240V single-phase hydraulic power unit. The lift is fitted with a 32A male plug and requires a suitable 32A female socket connected to an appropriately rated Type C or Type D motor circuit. All electrical provisions should be confirmed and installed by a qualified electrician.
Declaration of Conformity
The four-post triple-level parking lift complies with the UK Supply of Machinery (Safety) Regulations 2008 and the Electromagnetic Compatibility Regulations 2016.
Every lift is supplied with a Declaration of Conformity confirming compliance with the applicable UK regulatory requirements. You can download the Declaration of Conformity for the Four-Post Triple Stacker Lift below. here.Specifications
| Lifting Capacity | 2500kg |
| Height Of Post | 4368mm |
| Concrete requirement | 300mm |
| Outside Width | 2700mm |
| Total Length | 5060mm (5845mm with ramps) |
| Power Requirement | 240v 32C Fuse |
| Unit Weight | 1600kg |
FAQs
The Lift Giant four post triple level is the ideal car stacking lift for a range of different customers, from classic car storage businesses, to vehicle hire firms and even private collectors wanting to increase their car storage space.
Essentially the four post triple level parking lift is very much the same as a four post lift you would find in an MOT station. Using a 240v hydraulic pump this then powers a hydraulic cylinder in the platform. This then connected to the lifting cables which go from underneath the platform then round pulleys in the ends of the cross beams and up to the top of the posts.
As the hydraulic cylinder extends the cables then raise up the platforms until you either take your finger off the up button or the limit switch engages.
The unique design of our four post triple level parking lift means that the hydraulic cylinder is enclosed in the middle platform. The top platform is hollow and is in simple terms just a pallet that gets raised by the middle platform.
So when you want to raise the top platform up the two platforms travel up together until the lift reaches its very top limit switch. Then by pressing the lock button the top platform engages on lock hooks but the middle platform then continues on down for you to load the middle vehicle.
Due to the middle platform doing all the lifting and the top platform being just a pallet this means the top platform can sleave around the middle platform when it is down. This giving it a very low closed profile so great for driving on low sports cars.
Other triple level lifts on the market have separate top and middle level lifts which mean when they are down at ground level they are twice the thickness and the top level platform is near impossible to drive on to.
Additional benefit to our design is that the lift only has four posts. Making it look neater and not detracting from the cars being stored.
- 240v – 2000kg top level – 2500kg mid level
- Special low profile platforms
- Maximise car storage potential
- Multiple installation specialists
Yes this lift uses a 3kw 240v single phase motor. But due to it being a 3kw motor and there being a spike in current as the motor first turns they come fitted with a 32amp male plug and need to be on a motor rated ring main on your supply side.
We understand that all cars, be it classics or even modern supercars can drip fluids so we offer a selection of options for stopping fluids dripping from one car to another.
For top level we can offer metal infill panels to fill in the complete length between the platforms. These are an optional extra so not included in base price.
For the mid level due to the way the top level sleaves around the mid platform we can provide plastic trays that are lifting in once the middle car is lifted but are to be removed when you need to retrieve the top vehicle.
Collection only: Starting with you collecting your lift from our haulage depot on for example a flat bed trailer or in a long wheel base van, where we will load the stillage onto your transport with one of our forklift trucks. If this is your chosen option please do consider that the lift comes as one large metal stillage, so you will need to have suitable equipment for unloading at your end, such as an engine crane or forklift. It is supplied with a comprehensive installation manual with picture instructions, aimed at those with a mechanical understanding.
Delivery: We either have our own fleet of delivery vehicles or we can use our very good rates with a pallet network to get lifts all over the UK. For deliveries to addresses without unloading facilities such as residential addresses we can deliver with vehicles capable of unloading on your behalf. We have an option for all types of addresses so contact us with a bit of information about where you want your lift delivering too and we can quote you accordingly.
Installation: Due to our limited team capacity, we currently offer installation services for our two and four post double stackers only. For our triple stackers however, we provide detailed installation guides and support to assist you or your preferred installer. We offer a helpful contacts list of installation companies that you can contact to install your lift should you not wish to install it yourself, these are independent installation companies and have no affiliation or endorsement from Lift Giant Ltd.
Your lift comes with a 12 months parts warranty.
Although we can now offer extended parts warranty packages for your lift increasing it up to potentially 3 years. Contact us for pricing.
To successfully stack three cars on top of each other you will need a minimum of 5750mmmm of height. This is based on you parking three average height hatchback vehicles.
Due to the design of this lift and the top platform going up to catch on lock hooks you cannot adjust the height of the platform. Should you want to store three cars in a building with less height than this please contact us and we can provide you with a bespoke quotation.
Collection only: Starting with you collecting your lift from our haulage depot on for example a flat bed trailer or in a long wheel base van, where we will load the stillage onto your transport with one of our forklift trucks. If this is your chosen option please do consider that the lift comes as one large metal stillage, so you will need to have suitable equipment for unloading at your end, such as an engine crane or forklift. It is supplied with a comprehensive installation manual with picture instructions, aimed at those with a mechanical understanding.
Delivery: We either have our own fleet of delivery vehicles or we can use our very good rates with a pallet network to get lifts all over the UK. For deliveries to addresses without unloading facilities such as residential addresses we can deliver with vehicles capable of unloading on your behalf. We have an option for all types of addresses so contact us with a bit of information about where you want your lift delivering too and we can quote you accordingly.
Installation: Due to our limited team capacity, we currently offer installation services for our two and four post double stackers only. For our triple stackers however, we provide detailed installation guides and support to assist you or your preferred installer. We offer a helpful contacts list of installation companies that you can contact to install your lift should you not wish to install it yourself, these are independent installation companies and have no affiliation or endorsement from Lift Giant Ltd.
Your lift comes with a 12 months parts warranty.
Although we can now offer extended parts warranty packages for your lift increasing it up to potentially 3 years. Contact us for pricing.
To successfully stack three cars on top of each other you will need a minimum of 5750mmmm of height. This is based on you parking three average height hatchback vehicles.
Due to the design of this lift and the top platform going up to catch on lock hooks you cannot adjust the height of the platform. Should you want to store three cars in a building with less height than this please contact us and we can provide you with a bespoke quotation.
